2.5 Inch V-Band Exhaust Auto Spare Parts Flange Male Female Clamps
Product Detalls:
Our V-Band Assemblies utilize a 304 stainless clamp and flanges.
Our "Male/Female" flanges have an interlocking seating surface to
ensure proper alignment during installation. The butt-weld side of
the flanges offer a small groove that allows the flange and tube to
be aligned better prior to welding.
Each assembly includes one
For details, please contact us by mail, we will give you detailed
product information and prices.
Amy e-mail: export (at) ypmachinery.com
Wechat:Amy010086
whatsapp: 86 13739764346
product parameters:
| size(inch) | Flange inner diameter(mm) | Outer diameter of exhaust pipe(mm) | Material |
| 1.5 | 38.9 | 38.1 | SS304 |
| 1.75 | 45.3 | 44.5 | SS304 |
| 2 | 51.6 | 50.8 | SS304 |
| 2.25 | 57.9 | 57.1 | SS304 |
| 2.5 | 64.3 | 63.5 | SS304 |
| 2.75 | 70.6 | 69.8 | SS304 |
| 3 | 77 | 76.2 | SS304 |
| 3.25 | 83.3 | 82.5 | SS304 |
| 3.5 | 89.7 | 88.9 | SS304 |
| 3.75 | 96.1 | 95.6 | SS304 |
| 4 | 102.4 | 101.6 | SS304 |
| 4.5 | 115.1 | 114.3 | SS304 |
| 5 | 127.8 | 127 | SS304 |
| 6 | 153.2 | 152.4 | SS304 |
Features:
Rich configuration on both T Bolt and Nut and match various
application even critical like hih temperature, high vibration.
1. Whole stainless steel and resistant to corrosion;
2. Positive sealing integrity;
3. Easy assembly and disassembly;
4. High strength and reliable;
5. Good welding and physical performance .Outer diameter of exhaust
pipe
6. Bending by special technology means, it has a unique
anti-loosening spring design.
7. After the inner ring is tightened, the hose is rounded to ensure
that the hose can hold the hose tightly under elastic deformation
and various complex working conditions, with strong sealing.
Application:
The V-Band Clamps/Couplings offer effective fastening solutions in
exhaust systems,including filter frame, turbocharging system,
exhaust system and industrial application which need flange
connection. remove intercooler systems and turbo parts, such as
charge piping, intake pipes, diesel engines, turbochargers, and
heavy-duty exhaust systems.Etc
